Functions and Schematic of BAC219

inhae 2021. 10. 2. 12:19
  • ATMega Controller by Bilient, 2021.09

<Functions>

  • Motor Drive
  • IR Transmitter & Receiver
  • Analog Input(ADC0, ADC1, ADC2)
  • Serial Transceiver(RS-485)
  • Switch/Digital input
  • UART Communication
  • I2C Communication
  • Relay Control



<Schematic>
